The Zoom R12 MultiTrak recorder is made for musicians who want the freedom to make music wherever they go. Compact and mobile, you can record, edit and mix songs without a computer. Use the R12’s full-color LCD touchscreen to easily cut, copy, loop and edit your tracks.

R12 has super clean preamps, and you’ll love the way they sound. With two XLR/TRS inputs, and eight tracks of audio, the R12 is ideal for recording everything from demos to release-ready songs. It includes a send effects channel offering reverb, chorus and delay with a dedicated effects return fader.

For advanced tones, you can use presets and effects from Zooms’ Guitar Lab. The R12 also has pan and a 3-channel EQ for each track and a compressor on inputs 1 and 2. Use Sequence Play to create a playlist of your projects. Then use them as backing tracks, whether you’re playing live or rehearsing a set.

With 150 preloaded drum loops in a variety of patterns and genres, the R12 provides a versatile rhythm section for any project. Add additional audio samples by importing files into your R12 via Micro SD card or USB thumb drive.

The R12 provides up to five hours on four AA batteries (sold separately) allowing you to bring your production anywhere. Additionally, you can power the R12 with the optional AD-17 adapter (sold separately), or a USB battery. The R12 includes an 1/8" stereo headphone jack as well as dedicated 1/4" monitor outputs. Musicians can also plug in their iOS devices to use the optional R12 Control App.

Effects channel with reverb, chorus and delay
3-channel EQ for each track
Compressor on inputs 1 and 2
Create playlist of projects with Sequence Play
150 preloaded drum loops
3 Subpanels for connecting microphones, instruments or line level devices like keyboards, mixing boards and more
48V phantom power for condenser microphones

Mic/Line (Mono)
Inputs: 2
Connectors: 2 XLR/TRS combo jacks (Balanced, XLR: 2 HOT/TRS: TIP HOT
Input gain: +6 ~ +50dB
Input impedance XLR: 3.9 k ohm TRS: 3.9 kohm/1 Mohm (when Hi-Z ON, INPUT 1 only)
Phantom power: +48V (switchable separately for INPUTS 1 and 2)
Equivalent input noise: –121dBu or less (IHF-A) at +50dB/150-ohm input
Frequency response: −1.0/+0.5dB: 20Hz–20kHz
Master Out
Outputs: 1
Connectors: 2 TRS phone jacks (balanced)
Maximum output level: +14dBu
Output impedance: 200 ohm
Phones Output
Connectors: 1 stereo .137" (3.5 mm) mini jack
Maximum output level: 45 mW + 45 mW (into 32-ohm load)
Output impedance: 10 ohm
Recorder
Maximum simultaneous recording tracks: 2
Maximum simultaneous playback tracks: 8
Recording format: 44.1kHz, 16/24-bit, mono/stereo WAV
Recording media: 4–32GB cards compatible with the SDHC specification  64–1TB cards compatible with the SDXC specification
Track Settings
EQ High: 10kHz, ±12dB, shelving
Middle: 2.5kHz, ±12dB, peaking
Low: 100Hz, ±12dB, shelving
Pan: L100–R100
Effects
Input Dynamics: Comp/Limiter/Gate
Patch memory effects: 3 types can be used simultaneously
50 patch memories
Guitar Lab supported
Can be assigned and used as an insert (input) or send effect
Dedicated send effects: 10 types of spatial effects
Tuner
Chromatic/Guitar/Bass/Open A/Open D/Open E/Open G/DADGAD
CLICK (METRONOME)
Time signatures 3/4, 4/4, 6/8
Tempo range: 40.0–250.0 BPM
Time signatures: 3/4, 4/4, 6/8
Rhythm Loops
Sound source format: PCM
Number of loops: 150
Synth
Sound source format: FM
Polyphony: 8
Number of sound types: 18 (and a PCM drum kit)
Display
2.4" (320x240) full-color touchscreen LCD
USB
Connector: USB Type-C
Audio Interface Function
2-in/2-out or 2-in/2-out (iPad) USB 2.0 Full Speed
44.1kHz, 16/24-bit
2-in/4-out USB 2.0 High Speed
44.1kHz, 16/24-bit
Mass Storage Function
Device USB 2.0 High Speed (5 V/200 mA power supplied when host)
Guitar Lab Connection
USB 1.1 Full Speed
DAW Connection (Control Surface)
USB 1.1 Full Speed
Mass Storage Function
Host USB 2.0 High Speed (5V/200 mA power supplied)
USB MIDI Keyboard Connection
USB 1.1 Full Speed (5 V/200 mA power supplied)
Power
Batteries: 4 AA (alkaline, lithium, or rechargeable NiMH) (sold separately)
AC adapter: ZOOM AD-17 (5V/1.0A)
Estimated Continuous Operation Time Using Batteries
(During playback with +48V off and 32-ohm headphone load)
Alkaline batteries: about 5 hours
NiMH batteries (1900 mAh): about 5 hours
Lithium batteries: about 11 hours
